HV BESS 150 KWh Batteries With A Three Phase Grid-tied Inverter 80KW
2. Prismatic battery cell offers about 6500 times service life
Our HV BESS 150 KWh batteries with a three phase grid-tied inverter 80KW is a standard solution for big families or businesses. It's rack-mounted type with 4U, 3U, and 2U height options. The modular and plug-and-play designs make expansion easier, so you can get the capacity that you need. The top of the high voltage box can control and balance the whole battery system, checking the battery's status in real time on the screen. In addition, embedded BMS (battery management system) protects the battery with multiple protections.
Our high voltage BESS is a perfect solution for commercial & industrial energy storage system. With premium BMS technology, it's allowed to connect with most of the brand inverters in the market.
Parameter
| NO | Model No. | BP-HP-50KWH | BP-HP-100KWH | BP-HP-150KWH | BP-HP-200KWH | BP-HP-215KWH |
| 1 | Rated Voltage | 256V | 358.4V | 512V | 716.8V | 768V |
| 2 | Rated Capacity | 200Ah | 280Ah | 300Ah | 280Ah | 280Ah |
| 3 | Rated Energy | 51.2KWh | 100.3KWh | 153.6KWh | 200.7KWh | 215KWh |
| 4 | Voltage Range | 200V～292V | 280V～408.8V | 400V～574V | 627.2V～817.6V | 672V～864V |
| 5 | Cycles(80% DOD) | 8000 cycles | 8000 cycles | 8000 cycles | 8000 cycles | 8000 cycles |
| 6 | Depth of Discharge | 80% | 80% | 80% | 80% | 80% |
| 7 | Charge Current | 40A | 40A | 40A | 40A | 40A |
| 8 | Discharge Current | 40A | 40A | 40A | 40A | 40A |
| 9 | Maximum Continuous Charge Current | 160A | 160A | 160A | 160A | 160A |
| 10 | Maximum Continuous Discharge Current | 200A | 200A | 200A | 200A | 200A |
| 11 | Operation Temperature | Charge: 0℃~55℃,Discharge: -10~55℃ | ||||
| 12 | Display | LCD | ||||
| 13 | Cell Type | LiFePo4 Lithium Ion Phosphate Battery | ||||
| 14 | Communication | RS485/CAN/RS232 | ||||
| 15 | Compatibility | Compatible with most of available in/off-gird inverters and charge controllers | ||||
| 16 | BMS | Intelligent battery mangement system | ||||
Product Features
1. Hybrid solar system can store power via solar panels or grid
2. Independent battery management system has multiple protections
3. HV 80KW@150KWh ESS lowers the electricity cost
What Is an HV BESS 150 KWh Batteries With A Three Phase Grid-tied Inverter 80KW?
An HV BESS 150 KWh Batteries With A Three Phase Grid-tied Inverter 80KW is a commercial-grade energy storage platform featuring high-voltage battery racks (typically 600-950V DC) and a bidirectional three-phase inverter. The system stores 150 kWh of nominal energy while providing up to 80kW of AC power output, suitable for grid-tied operations with seamless support for solar PV integration.
The configuration typically uses modular LiFePO4 cells for superior safety and longevity, with an advanced Battery Management System (BMS) and Energy Management System (EMS) for optimized performance.
An HV BESS 150 KWh Batteries With A Three Phase Grid-tied Inverter 80KW is a commercial-grade energy storage platform featuring high-voltage battery racks (typically 600-950V DC) and a bidirectional three-phase inverter. The system stores 150 kWh of nominal energy while providing up to 80kW of AC power output, suitable for grid-tied operations with seamless support for solar PV integration.
Installation Policy
Solar energy system products require professional technicians to install. For safety reasons, we do not recommend that customers install solar products themselves unless they are professional technicians.
We can provide technical support during the installation process. If you have any questions, please send us the relevant photos and videos for communication and check. We will provide online technical services in time.
Product qualification
Compatible Inverters
Packaging
About us
FAQ
Q：Do you manufacture lithium batteries?
A：Yes, our factory specializes in the production of lithium batteries and has been doing for more than 10 years.
Q：Is there a minimum order quantity requirement?
A：No.order one and we can also sell.
Q：Are there any discounts available for large orders?
A：We offer varying discounts based on the size and scope of your order.
