48V 280Ah 10KW LiFePo4 Battery Pack For Solar Energy Storage
2. Fully metal shell to protect the lithium battery pack
The bess solar battery energy storage system lithium ion battery is a high-performing deep cycle reach up to 6500 times LiFePo4 battery cells built on patented Lithium Iron Manganese Phosphate chemistry.it can provide low voltage to high voltage 24v 36v 48v 51.2v 60v and 72v optional,besides we accepted OEM/ODM service for all products
Parameter
|
NO |
Model No. |
BP-HR-7KWH |
BP-HR-10KWH | BP-HR-13KWH | BP-HR-15KWH |
|
1 |
Rated Voltage |
51.2V |
51.2V |
51.2V |
51.2V |
|
2 |
Cell Combination Type |
16S |
16S |
16S |
16S |
|
3 |
Rated Capacity |
150Ah |
200Ah |
250Ah |
300Ah |
|
4 |
Rated Energy |
7.68KWh |
10.24KWh |
12.80KWh |
15.36KWh |
| 5 | Voltage Range | 40V～58.4V | 40V～58.4V | 40V～58.4V | 40V～58.4V |
|
6 |
Cycles(80%DOD) |
6500 cycles |
6500 cycles | 6500 cycles | 6500 cycles |
|
7 |
Depth of Discharge |
80% |
80% | 80% | 80% |
|
8 |
Charge Current |
20A |
40A |
40A |
40A |
|
9 |
Discharge Current |
20A |
40A |
40A |
40A |
|
10 |
Maximum Continuous Charge Current |
80A |
160A |
160A |
160A |
|
11 |
Maximum Continuous Discharge Current |
100A |
200A |
200A |
200A |
|
12 |
Weight |
85kg |
105kg |
125kg |
155kg |
|
13 |
Dimension L*W*D(mm) |
L500*W230*H630mm |
L500*W250*H650mm |
L520*W250*H700mm |
L520*W250*H750mm |
|
14 |
Operation Temperature |
Charge: -10℃~55℃,Discharge: 0~55℃ |
|||
| 15 | Storage Temperature | Keep at -10℃ to 55℃ | |||
| 16 | Cell Type | LiFePo4 Lithium ion Phosphates Battery | |||
| 17 | Maintenance | Maintenance free | |||
| 18 | Compatibility | Compatible with most of available off-gird/hybird inverters and charge controllers | |||
| 19 | BMS | Intelligent battery mangement system | |||
| 20 | Maximum Parallel/Moduler Connection | 16pcs | |||
Product Features
1. This energy storage battery 24v 36v 48v 51.2v 60v 72v optional.
2. Exceeds 6500 times cycle life with 80% DOD.
3. Accepted customized low voltage and high voltage 24v-96v.
We have two types of roller battery, and we accept OEM/ODM services
Product qualification
Install
Packaging
About us
FAQ
Q：Do you offer samples and is it free of charge?
A：we need to collect the sample charge.
Q：What is the estimated delivery time for your batteries?
A：The delivery time for the batteries ranges from 5 to 25 working days after the receipt of the advance payment. The exact delivery timeline will depend on the products ordered and the quantity of the order.
Q：What is the warranty policy for the battery?
A：The warranty for the battery varies, ranging from 5 to 10 years, depending on the specific model.
