Floor Mount 30KWh LiFePO4 Big Battery Storage
2、Power source from PV, grid, and generator
The floor mount 30kWh LiFePO4 big battery storage is designed to be simple and beautiful, making it suitable to place on the ground with pleasure. This is a green power solar storage system for home, an environmentally friendly floor mount 30kWh LiFePO4 big battery storage produces no pollution during operation. By connecting with a hybrid inverter, the floor mount 30kWh LiFePO4 big battery can convert DC that is stored in the battery into AC to charge the home equipment.
Parameter
|
NO |
Model No. |
BP-HR-20KWH-B |
BP-HR-25-BKWH |
BP-HR-30KWH-B |
|
1 |
Rated Voltage |
51.2V |
51.2V |
51.2V |
|
2 |
Cell Combination Type |
16S2P |
16S2P |
16S2P |
|
3 |
Rated Capacity |
400Ah |
456Ah |
560Ah |
|
4 |
Rated Energy |
20.48KWh |
23.35KWh |
28.67KWh |
| 5 | Voltage Range | 40V～58.4V | 40V～58.4V | 40V～58.4V |
|
6 |
Cycles(80%DOD) |
6500 cycles |
6500 cycles | 6500 cycles |
|
7 |
Depth of Discharge |
80% |
80% | 80% |
|
8 |
Charge Current |
40A |
56A |
56A |
|
9 |
Discharge Current |
40A |
140A |
140A |
|
10 |
Maximum Continuous Charge Current |
160A |
200A |
200A |
|
11 |
Maximum Continuous Discharge Current |
200A |
200A |
200A |
|
12 |
Weight |
150kg |
190kg |
230kg |
|
13 |
Dimension L*W*D(mm) |
L720*W450*H600mm |
L740*W450*H650mm |
L740*W450*H680mm |
| 14 | Battery Type | Wheel Battery | ||
| 15 | Operation Temperature | Charge: 0℃~55℃,Discharge: -10~55℃ | ||
| 16 | Storage Temperature | Keep at 0℃ to 55℃ | ||
| 17 | Cell Type | LiFePo4 Lithium ion Phosphates Battery | ||
| 18 | Maintenance | Maintenance free | ||
| 19 | Compatibility | Compatible with most of available off-gird/hybird inverters and charge controllers | ||
| 20 | BMS | Intelligent battery mangement system | ||
| 21 | Maximum Parallel/Moduler Connection | 16pcs | ||
Similar Products
Power Battery Generator With Lifepo4 Highlight :
Rechargeable household energy storage battery with no pollution
Featuring an intelligent battery management system for safety
Each battery pack offers over 6000 cycles of charging and discharging
Less weight compared with a traditional battery in the same capacity
Plug-and-play design simplifies the installation
Green power without hazardous substances, reducing your carbon footprint
Meeting the international standards, our roller lithium battery is one of the best home energy storage solutions, each battery with smart BMS enhances the safety. Battery can be charged from solar during the day, and discharge it when ourtage, a worthwhile solar battery invest for the long-term run.
Price Advantage
We cannot promise that we can offer you the lowest price, but we can promise that we can offer you the best price, which means you can get the best quality products at a reasonable price. We will not sacrifice product quality to attract customers at low prices, Doing one-off business is not our goal. We hope to support our customers in expanding their businesses, we always know customer prosperity is our priority.
May be you will like
FAQ
Q: How long does it take to fully charge the battery?
A: The charging time of the battery will vary based on the total power of the solar panles and the weather.
Q: What is the temperature range for operating the battery?
A: The operating temperature range of our batteries is typically between -10°C to 55°C.
Q: Are energy storage batteries suitable for use in cold temperatures?
A: The operating temperature range of our batteries is typically between -10°C to 55°C,we won't recommend to use in temperature lower -10°C.
Q: Is there a warning function for low battery levels in the battery?
A: The battery can be equipped with an early warning function, providing real-time monitoring of battery parameters and prompt notifications to users for timely resolution of any issues.
Q: How do I activate the battery?
A: Before utilizing your battery for the first time, it is important to activate it by charging and discharging with a current greater than 1A, and to measure the terminal voltage to confirm it is functional. To prolong the battery's lifespan, it is recommended to disconnect it from the system before prolonged storage. After 24 hours, the battery will enter its automatic mode.
