Big Capacity For Hybride Inverter 5kw Wall Mounted Battery IP65 Level
2.Powerwall 7KWh battery 51.2V with 135Ah
This is a wall-mounted battery for home energy management that can store 7KWh of energy, by compaction with an inverter, it can store electricity from solar panels or be charged from the grid, and you can tell the battery's conditions easily from the inverter.
When using our wall mounted 5kw solar battery backup system for households, you don't need to worry about the grid cut, because the full-charged backup battery will support your loads to work as usual. When large-capacity battery storage is required, connecting with the same battery in parallel will meet it.
Parameter
|
NO |
Model No. |
BP-HP-5KWH-C |
BP-HP-7KWH-C |
BP-HP-10KWH-C |
|
1 |
Rated Voltage |
51.2V |
51.2V |
51.2V |
|
2 |
Cell Combination Type |
16S |
16S |
16S |
|
3 |
Rated Capacity |
100Ah |
135Ah |
200Ah |
|
4 |
Rated Energy |
5.12KWh |
6.91KWh |
10.24KWh |
| 5 | Voltage Range | 40V～58.4V | 40V～58.4V | 40V～58.4V |
|
6 |
Cycles(80%DOD) |
6500 cycles |
6500 cycles | 6500 cycles |
|
7 |
Depth of Discharge |
80% |
80% | 80% |
|
8 |
Charge Current |
20A |
20A |
40A |
|
9 |
Discharge Current |
20A |
20A |
40A |
|
10 |
Maximum Continuous Charge Current |
80A |
80A |
160A |
|
11 |
Maximum Continuous Discharge Current |
100A |
100A |
200A |
|
12 |
Maximum Continuous Charge/Discharge Current |
5.12KW |
6.19KW |
10.24KW |
|
13 |
Weight |
60kg |
80kg |
120kg |
|
14 |
Dimension L*W*D(mm) |
L650*W384*H142mm |
L650*W420*H135mm |
L680*W412*H231mm |
|
15 |
Battery Type |
Wall-mounted |
||
|
16 |
Operation Temperature |
Charge: -10℃~55℃,Discharge: 0~55℃ |
||
| 17 | Storage Temperature | Keep at -10℃ to 55℃ | ||
| 18 | Cell Type | LiFePo4 Cell | ||
| 19 | Maintenance | Maintenance free | ||
| 20 | Compatibility | Compatible with most of available off-gird/hybird inverters and charge controllers | ||
| 21 | BMS | Intelligent battery mangement system | ||
| 22 | IP Protection | IP 65 | ||
| 23 | Maximum Parallel/Moduler Connection | 16pcs | ||
Product Features
1. IP65 design to resist water and dust, last service life.
2. Just plug and play.
3. 6,500 times deep cycle device has over 15 years lifespan.
Energy storage battery type
Currently, commonly used energy storage batteries include lead-acid batteries and lithium-ion batteries. Lead-acid batteries have lower costs and mature technology, but relatively lower energy density and shorter lifespan. Lithium-ion batteries have high energy density, long lifespan, and high charge/discharge efficiency, but higher costs. In some cost-sensitive small-scale photovoltaic energy storage systems, such as small-scale photovoltaic energy storage systems for rural households, lead-acid batteries may be a choice. However, for large-scale industrial and commercial photovoltaic energy storage systems or off-grid photovoltaic systems with higher performance requirements, lithium-ion batteries are more suitable.
Distributor Policy
SUPPORT: we can offer online technical assistance and offline technical service if necessary.
EXCLUSIVE: we can design exclusive products' appearance for distributors which other customers cannot use.
MOQ: 20-foot container for each order, which can include a few kinds of products.
PRICING: Distributors can get lower prices than any other customers in the same country.
MARKETING: we can design marketing posters or brochure for distributor anytime for free.
Our factory is equipped with advanced equipment and production lines, which enable us to meet the ever-changing needs of our growing customers. Every product we supply meets the highest quality standards.
Product qualification
Install
Packaging
About us
FAQ
Q：How can I obtain the price list for your products?
A：:For a detailed price list, please provide us with your preference products and quantity ,we'll get back to you promptly with the requested information.
Q：What is the method of delivery for the battery?
A：Typically, batteries are shipped via air or sea.
Q：Is it possible for us to act as your agent?
A：Of course, we welcome you being our agent.
