Industrial Energy Storage Systems BESS 5MWh Liquid Cooling System
1. UN38.3/MSDS/CE/IEC/FCC Certificates
2. Grade A Lithium Ion Battery
3. Liquid Cooling System
4. Intelligent Energy Management System
5. More than 8000 times cycle life
The Industrial Energy Storage Systems BESS 5MWh Liquid Cooling System is a containerized bess system battery solution designed for utility-scale and commercial operations. Typically housed in a 20-foot container, it utilizes lithium iron phosphate (LFP) cells with a nominal capacity of around 5.015 MWh, delivering high safety, long cycle life, and stable performance. As a mature product from a professional bess battery energy storage systems factory, the system is engineered for continuous operation under demanding industrial conditions.
The advanced liquid cooling mechanism circulates coolant through dedicated plates or channels, ensuring uniform temperature control across the battery modules. This design effectively prevents thermal runaway and extends battery lifespan, which is critical for large-scale bess system solar projects that require reliable energy shifting and peak shaving. By maintaining optimal thermal conditions, the system supports higher energy efficiency and consistent output.
In addition, the solution seamlessly integrates power conversion systems (PCS), battery management systems (BMS), and fire suppression units into a compact container. This high level of integration allows the system to function efficiently as part of a complete bess pv system, enabling smooth renewable energy integration, frequency regulation, and grid stabilization. Backed by BLOOPOWER, the 5MWh liquid-cooled BESS provides a scalable, safe, and intelligent energy storage option for modern industrial and utility applications.
Parameter
| Item | Parameters |
| PCS Rated Power | 2500KW |
| Battery Type | LiFePO4 Battery |
| Cell Capacity | 314Ah |
| Battery Pack Quantity | 416S12P |
| System Capacity | 5015.96KWh |
| Rated DC Voltage | 1311.2V |
| DC Voltage Range | 1086V ~ 1497.6V |
| Rated Grid Frequency | 50Hz/ 60Hz |
| AC Voltage | 690Vac |
| Working Mode | Grid-tied peak shaving/off-gird power supply guarantee |
| Noise | <75db |
| Max Conversion Power | 99.0% |
| BMS Protection | Over temperature, low temperature charging, over current, short circuit, over voltage, under voltage, DC bus protection,etc. |
| System Life | >8000 cycles@DOD 80% |
| THDi | <3%(rated power) |
| Operating Temperature | -20℃~45℃ |
| Maximum Altitude Allowed | ≤4000m |
| IP Grade | IP54 |
| Size | 12192mm*2438mm*2591mm |
| Container Size | 40foot |
| Storage Temperature | -20℃~45C |
| Fire Extinguishing System | Perfluorohexanone gas fire extinguishing system+water sprinkler |
| Cooling System | Liquid cooling |
| Corrosion Level | C3/C4/C5(optional) |
Similar Products
Power Battery Generator With Lifepo4 Highlight :
Connecting four of the 1250KW/2609KWh systems in parallel for 5000KW/10MWh ESS
Application: data centers, power stations, hospitals, factories, schools, etc.
Support cloud scheduling and operational report analysis
ESS-in-a-box solution minimizes installation time
Tier 1 lithium-ion batteries with high energy density and long cycle life
Support customizing voltage, cooling system, current, capacity, IP level, and so on
Why Choose Liquid Cooling for Your Industrial Energy Storage Systems BESS 5MWh Liquid Cooling System?
Liquid cooling offers superior thermal management compared to air-cooled alternatives, a key factor in the benefits of liquid cooling in 5MWh battery electric storage system BESS deployments. Through precise temperature regulation coordinated by the bess control system, liquid cooling can achieve temperature uniformity within ±2 °C, reducing cell degradation by up to 22% and extending cycle life beyond 8,000 cycles.
In the Industrial Energy Storage Systems BESS 5MWh Liquid Cooling System, these advantages translate into higher usable energy density-up to a 45.8% increase per container-and overall system efficiency exceeding 89%. The integrated energy management system in BESS continuously monitors load demand, state of charge, and thermal conditions, optimizing charging and discharging strategies to maximize performance and asset life.
In a broader industry context, the abbreviation behavioral and emotional screening system BESS is sometimes encountered in non-energy fields, but within energy storage it is clearly defined as a high-performance, intelligent battery solution. When combined with advanced control and management architectures, liquid-cooled BESS platforms deliver the reliability, efficiency, and scalability required for modern utility-scale and industrial energy storage applications.
Warranty Policy
For Energy storage batteries, we offer 10 years warranty to give customers peace of mind. Within 10 years, maintained for free. During use, if there has any technical questions, our technical team will give you the solutions soon. if need to replace any accessories and it is not caused by human factors, we will arrange to send the accessories as soon as possible within the warranty period. As for distributors or large-scale projects, if the problem cannot be solved online, our professional technicians will solve it on-site.
